| production capacity | 100L | 200L | 300L | 500L | 1000L | 2000L |
| Floor space | ≥15m² | ≥25m² | ≥35m² | ≥50m² | ≥80m² | ≥120m² |
| Total power | 12kw | 12kw | 12kw | 15/36kw | 22/72kw | 31/144kw |
Consumption of water(Max) | 0.2m³/h | 0.4m³/h | 0.5m³/h | 1.0m³/h | 1.5m³/h | 2.0m³/h |
Total water consumption per day | 0.5m³/h | 1.0m³/h | 1.5m³/h | 2.5m³/h | 5.0m³/h | 10m³/h |
| Consumption of malt | 20kg | 40kg | 60kg | 100kg | 200kg | 400kg |
| Consumption of hops | 60g | 120g | 180g | 300g | 600g | 1.2kg |
| Yeast | 100g/1L | 200g/2L | 300g/3L | 500g/5L | 1kg/10L | 2kg/20L |
| Steam | | 0.017t/hr | 0.017t/hr | 0.05t/hr | 0.10t/hr | 0.20t/hr |
PRODUCT FEATURES:
1- Desiging tanks and heating system according to craft, mash tank
warming≥10℃/min
2- Energy saving stir structure : large cross-section impeller,
15r/min speed
3- Sieve plate of filter tank includes welding sieve plate and
milling sieve plate.
4- Plow knife of filter tank separated to one foot, feet and bow
plow knife
5- Wort boiling heat way includes steam jacket, interior heating
and exterior heating.
6- Material includes stainless steel 304, 316 and red copper
Whether your in need of additional Fermenters or Bright Tanks for
your existing brewery, or need an entire Brewhouse we have you
covered. We can have any tank custom built to your specific size
and style requirements. Copper Cladding is available on any
fermenter, bright tank, mash tun/ brew kettle, lauter tun/
whirlpool etc.
Before-Sales
1. Layout Design for new build brewery
Our experienced engineer( more than ten years) will provide the
detailed layout according to your brewery, if needed, we will fly
to your brewery at our cost.
2. Exist Brewery Expansion
Expansion of the brew house, beer tanks, or other parts, we will
design and manufacture as per your exist brewery.
3. Effective business communication
Our sales team are young and rich of experience, we are full of
passion, all of us have been in this business line for more than 8
years, and they are graduated from UK, Russia etc.
4. Brewing consultant
We also bult a good relation with Shandong university and other
institutes who are expert in beer brewing, we are capable to
provide the most advanced brewing technology.
After-Sales Service
1. Guarantee: 3 years
2. Installation: Our engineers team will provide you the perfect installtion and
commissioning service. Almost of them have been to 5 countries even
more.
Except brewhouse and fermenter, there is many other auxiliary
equipment included in complete brewery equipment.
Such as grain miller, bright beer tank, glycol chilling unit,
control system, CIP cart.
