Product Discretion:
,
Useful capacity:500L.(+25% head space)
Outline size: φ1270*2400 mm.
Inner:SS304.TH=3.0mm Outer:SS304.TH=2.0mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.4~0.6 μm without dead
corner
Insulation: Polyurethane; TH=80mm
Glycol Jacket: Dimpled plate on cone and side
Dished head and 60 degree cone bottom
Top Manhole:φ330*430mm.
CO2 blow-off arm with butterfly valve
Full sanitary sampling valve_Perlic Style
Mechanical relief valve 2 bar on CIP arm
Shockproof pressure gauge on CIP arm
Dry hopping port with solid end cap
Thermowell for high accuracy temperature sensor
Fermentation tank pressure:Design pressure 0.5MPa;Working pressure
0.2Mpa.
Product advantages :
1- we support installation and debugging, technical guidance on
site
2- engineer will teach how to brewing and running the production
line, test the beer’s quaity
3- design drawing for free
4- competitive and low price of raw material
5- high quality of the beer equipment
6- competitive price
7- highly automatic or manual operation
8- material: SS304 or red copper
Shun Long Servie
Pre-sale service:
1. Make the equipment details specifications to customers
2. We can supply the OEM process, according to the drawings, the
samples to customized the beer equipment
3. Layout plan in CAD drawings of beer machine.
4. The competitive price and the timely delivery.
After-sale service:
1. Provide the required customs declaration files, timely tracking
freight
2. The equipment main configurationgs for 3 years warranty time,
such as the valves and so on.
3. Professional engineers for installation, commissioning,
maintenance.
4. Directed by executable remote installation(with no experience in
beer, equipment installation experience, can also perform
operations, please make this clear before custom equipment, we have
successful cases)
If you are interested in our machines, please don't hesitate to
contact me.
We can meet you what you want, looking forward to your inquiry.
Let's go together in the process of cooperation to the good
prospects.
