| Capacity | Cylinder(ODxH) | TOTAL HEIGHT | Inner Thickness |
| 3BBL | 960x750mm | 1880mm | 3mm |
| 5BBL | 1060x850mm | 2250mm | 3mm |
| 7BBL | 1160 x 900mm | 2450mm | 3mm |
| 10BBL | 1260 x 1150mm | 2800mm | 3mm |
| 15BBL | 1500 x 1220mm | 3100mm | 3mm |
| 20BBL | 1600 x 1400mm | 3500mm | 3mm |
| 30BBL | 1800 x 1650mm | 3760mm | 3mm |
| 40BBL | 1900 x 1850mm | 4210mm | 3mm |
| 50BBL | 1900 x 2050mm | 4750mm | 3mm |
| 60BBL | 2200 x 2150mm | 4830mm | 4mm |
| 80BBL | 2200 x 2900mm | 5780mm | 4mm |
| 100BBL | 2200 x 3600mm | 6450mm | 4mm |
More details
Design pressure 45 psi (3bar); working pressure 15psi (1bar)
4 stainless steel legs with leveling footpads
Interior shell: 304 stainless steel, thickness 3mm
Exterior shell: 304 stainless steel, thickness 2mm
Interior and exterior finish bright polish to 0.6~0.8, hygiene
surface
60 degree cone bottom, other angles can be specified during the
design process
Combined drain extensions and beer port in cone are standard
25% headspace, unless a different volume is requested
Top manway or side manway door
Dual zone in sidewall and cone dimple cooling jacket with glycol
inlet and outlet
Polyurethane insulation thickness 80mm for cooling jacket on side
and bottom
Fully welded exterior shell
Non welding CIP arm and rotating 360 degree reach spray ball
Solenoid relief valve, pressure relief valve (safe valve) are
standard
Pressure gauge
Temperature sensor well
Sanitary sample valve and port
All clamps and gaskets to attach all accessories
Tank complete with piping, fittings, sanitary valves and all parts.
Carbonation port is available for special request (stone not
included)
Ladder hooks is available for special request
Dry hop ports and/or hop bag hooks in any fermenter of any size for
special request
If you are would like to change, add, remove or modify any part of
the tanks, we can accommodate that. Specific fitting sizes, changes
and locations will be set during the design process after a deposit
is taken.
