Industrial Craft Beer Brewing Equipment 1000L Conical Fermenters Steam Heating

Ask Lasest Price
Brand Name :	SLET
Model Number :	SL-1000
Certification :	CE ISO
Price :	USD 75,000-100,000 PER Set
Payment Terms :	T/T
Supply Ability :	30 Sets per Month
Delivery Time :	30 working days after the deposit arrival

Add to Cart

Product Details
Company Profile

Industrial Craft Beer Brewing Equipment 1000L Conical Fermenters Steam Heating

500L 1000L 1500l 2000l Industrial beer brewing equipment, beer machine for craft beer brewing

Product details

Good abrasion resistance material
Inner-Jacket(SUS304)thickness: 3.0mm
External-Jacket thickness: 2.0mm
Seal head thickness: 3.0mm
High quality insulation effect
Polyurethane thickness: 80mm
Beautiful weld and polish technology
All argon gas protection welding. Polishing precision up to Ra0.6µm.
Powerful technology supporting
Providing drawing of every tank and drawing the layout of the whole project according with
customer’s workshop
World’s top brands’ electronic components
For example, we use Siemens PLC and touch screen, Schneider button of circuit breaker, Airtac electromagnetic valves and other pneumatic parts, etc.
CE certificate and UL certificate
All our products can pass CE certificate. If you need, we can also apply the UL certificate for you.
Good aftersales service

Details In form

Product Name	1000L beer machine large micro beer brewing equipment brewery tanks
Appearance	Stainless steel or Copper clading
Color	Mirro SUS, Luxury red copper
Standard	1BBL-100BBL
Thickness of Tanks	3mm for interior shell / 2mm for exterior shell
Heating method	Electric / Steam / Direct fire
Inner Polishing Precision	0.6 Micrometer
Plants Type	Turnkey or Customerized

Analysis of the brewery

I Power

Output/Brew	1HL	3HL	5HL	6HL	8HL	10HL
Brew/Week	2~6	2~6	2~6	2~6	2~6	2~6
Output/Week	2~7HL	6~18HL	10~30HL	12~36HL	16~48HL	20~60HL
Electric Supply	3phase/380(220, 415,440…)v/50 (60)Hz Single Phase/ 220(110, 240…)v/50(60)Hz
Heating Source	Electric/Steam
Area Request	>20M2	>30M2	>45M2	>50M2	>60M2	>70M2
Brewmaster	1	1	1	1	1	1

II Water & land requirement

Model Items	SL-0.1	SL-0.2	SL-0.3	SL-0.5	SL-1.0	SL-2.0
Capacity	100L/Day	200L/Day	300L/Day	500L/Day	1000L/Day	2000L/Day
Area Request	15M2	25M2	40M2	50M2	85M2	130M2
Installed Power	10Kw	15Kw	22Kw	35Kw	45/15Kw	70/15Kw
Water Consumption	0.6M3/Day	0.8M3/Day	1M3/Day	1.5M3/Day	3M3/Day	5M3

Shun Long Advantage

1. The unite can meet the wort production requirements of self- made beer bar and can complete the whole process from grinding of raw material, material feeding, saccharification, wort filtration, boiling, settling and cooling to the final oxygenation.
2. The whole equipment are made of high quality stainless steel which meets the international and national hygiene and safety standards.
3. There are two heating methods: steam heating and electrical heating
4. Saccharification filtration tank is equipped with variable frequency mixer which can achieve the exchange of rotating speed from 50r/min and meet the requirements of rotating speed for saccharification mixing and filtration tank mixing.
5. Operation and control are achieved by automatic control or semiautomatic control with computer industrial control system.
6. Input and output of material and self- circulation are connected by sanitation material pump and hose and the cleaning adopts CIP cleaning tanker and hose connection to achieve self-circulation cleaning.
7. Connection type of pipelines for requirements is quick assembly which is convenient for cleaning, maintenance and repair during production.
8. Reasonable design, delicate, process, nice appearance, durable service, easy for operation, repair and maintenance.

Shun lONG Brewery Configuration

1000L small Beer Making System
Brewing System	Components	Capacity	Specification
Grinding System	Miller	300KG/H	Double Roller,Noise<60db
Heating System	Boiler	100KG/H	Electric,Gas,Oil,Coal Type/CE certification
Brewhouse System	Mash/Lauter tun	1000L	Mashing Process:Decoction.Infusion.Multi-step infusion Heating source:Steam,Electric,Gas SUS304/Red copper
	Brew Kettle/ Whirlpool Tank	1000L
	Hot Water Tank	1500L
	Heat exchanger	10SQM	Stainless steel plate
Fermentation System	Fermentation Tank	1000L/2000L	Top manway/Side manway Drying hop port to brew IPA Dimple Plate Cooling jacket Carbonation port to fill CO2
Fermentation System	Yeast Adding Tank	10L	SUS304 Stainless Steel
Cooling System	Glycol Water tank	3000l	Equiped with PU level indicator
	Chiller	10HP	UL/CE certified electric elements,Copeland compressor
	Pump	3T
Cleaning System	Disinfection Tank	100L	SUS304 full welded
	Alkali Tank	100L
	Pump	3T
Control System	Control Cabinet	Manual/PLC/ HMI	Manual/Semi-automatic/Automatic
Optional	Auger System
	Grain Case
	Grist Hydrator
	Piping flow panel for Brewhouse
	Brewhouse Separate PLC Controller
	Customized fermentation tank

Shun Long Service

Pre-service
Our market team can serve you in 24 hours, so please feel free to contact at your convinent.
Our dedicated engineers can supply 2D, 3D drawing for you if you needed.
If you need to inspect our factory, we can book the hotel and make the invitation letter for you.
Our market team with our engineer with more than 10 years experiences together can satisfy you with
any technology problem;
Customize machine can be offered(voltage, material, dimension, heating source and so on)
After-service:
When shippment, we will supply a whole set of parts for backup.
If there is any parts damaged, we are surely can send the part to you in 24 hours.
Main machine is 3 years warranty, auxiliary machine is 12 months warranty,
electrical components is 18 months warranty, life long service.
